What Is Cathodic Inspection?

Cathodic inspection is the process of evaluating the performance of cathodic protection (CP) systems. These systems are designed to prevent corrosion by making the protected structure the cathode of an electrochemical cell, either through galvanic (sacrificial anode) systems or impressed current systems. Regular inspections verify that these systems are functioning effectively, reducing the risk of corrosion-related failures.

Key components of a cathodic inspection include:

• Measuring pipe-to-soil potentials to assess protection levels.
• Inspecting anodes for wear and effectiveness.
• Monitoring rectifier output in impressed current systems.
• Identifying signs of coating damage or environmental changes that could affect protection.

Why Is Cathodic Inspection Critical?

1. Ensures Asset Integrity
   Corrosion is one of the leading causes of infrastructure failure in the midstream sector. Regular inspections help detect early signs of system degradation, allowing for timely maintenance that extends the lifespan of assets.


2. Protects Against Environmental and Financial Risks
   Pipeline leaks or failures can lead to significant environmental damage and costly fines. Cathodic inspections help prevent these incidents by ensuring that protective systems are operating as intended.


3. Maintains Regulatory Compliance
   Energy industry regulations mandate cathodic protection for pipelines and other midstream infrastructure. Regular inspections ensure compliance with standards set by organizations like the National Association of Corrosion Engineers (NACE) and the Pipeline and Hazardous Materials Safety Administration (PHMSA).

Key Steps in a Cathodic Inspection Process

1. Initial Survey
   A baseline assessment is conducted to gather data on the current state of the CP system. This includes soil resistivity measurements and pipe-to-soil potential readings.


2. Visual and Electrical Checks
   Inspectors examine rectifiers, anodes, and test stations for physical damage and confirm that electrical output is within the required range.


3. Data Analysis
   Collected data is analyzed to identify areas of concern, such as insufficient protection levels, coating failures, or anode depletion.


4. Reporting and Recommendations
   A comprehensive report is prepared, detailing the inspection findings and providing actionable recommendations for system optimization or repair.

Challenges in Cathodic Inspections

• Access to Remote Locations: Pipelines often traverse remote areas, making inspections logistically complex. Innovative technologies like drones and remote monitoring systems are addressing these challenges.
• Environmental Variability: Soil resistivity, temperature, and water salinity can vary significantly, affecting cathodic protection performance.
• Aging Infrastructure: Older pipelines may have outdated systems that require modernization to meet current standards.

Percheron’s Expertise in Cathodic Inspection

At Percheron, we understand the complexities of midstream operations and the importance of maintaining corrosion-free infrastructure. Our cathodic inspection services provide:

• Comprehensive Assessments: From baseline surveys to detailed rectifier checks, our inspections cover every aspect of cathodic protection.
• Advanced Technology: We leverage cutting-edge tools and techniques, including real-time monitoring systems, to deliver precise and actionable insights.
• Experienced Professionals: Our team includes certified experts who ensure compliance with NACE and PHMSA standards.

The Future of Cathodic Inspection

The integration of advanced technologies is revolutionizing cathodic inspections, making them more efficient and effective:

• IoT-Enabled Monitoring: Internet of Things (IoT) devices provide real-time data on CP system performance, enabling predictive maintenance.
• AI and Machine Learning: These tools analyze inspection data to identify patterns and predict potential failures.
• Sustainable Practices: New eco-friendly anodes and coatings are reducing the environmental footprint of cathodic protection systems.

Conclusion

Cathodic inspection is essential for safeguarding midstream infrastructure, protecting the environment, and maintaining compliance with industry standards. With Percheron’s expertise, you can ensure that your assets remain secure and operational, minimizing risks and maximizing efficiency.
For more information on how our cathodic inspection services can benefit your operations, contact Percheron today.
